Industrial Shrink Film Wrap Packaging Machine QL5545 +BS-D4520

QL5545 +BS-D4520 shrink-wrap packaging machine heats and shrinks plastic film to wrap items for protection and aesthetics, it is a kind of equipment widely used in the packaging industry. This type of machine is highly efficient, fast, and cost-saving, so it is widely used in modern packaging processes.

  Description

The shrink-wrap packaging machine heats and shrinks plastic film to wrap items for protection and aesthetics, it is a kind of equipment widely used in the packaging industry. This type of machine is highly efficient, fast, and cost-saving, so it is widely used in modern packaging processes. The heat shrink packing machine is widely used in single, collective, or combined packaging of food, beverage, medicine, daily chemical, hardware, wood products, stationery, printing products, plastic products, glass products, electronic components, and other products.

The heat shrink film packaging machine’s working principle is very simple. It heats the film to make it soft, then puts the item into the film, and finally shrinks the film by cooling and wrapping the item tightly. This type of machine is flexible because it can accommodate items of different shapes and sizes.

Heat Shrink Film Packaging Machine Advantages

PLC program;
Alloy sealing knife;
Self-winding scrap;
Photoelectric induction;
Fully automatic sealing and cutting;

shrink wrap packing machine

QL5545 +BS-D4520 Shrink Film Packing Machine Parameter

Model BS-D4520
Voltage 220V/50-60HZ
Power 8.5KW
Tunnel size(mm) 800L*450W*200H
Temp. Range 0-300℃
Max.Load 10KG
Speed 0-15m/min
Machine Size(mm) 1600L*730W*1400H
Weight 210KG
 Model QL5545
Voltage 220V/50-60HZ
Power 1.3KW
Packing speed 1200-1600pcs/h
Max. sealing size 500*450mm
Machine Size(mm) 1700L*900W*1400H
Weight 260KG



Temperature time checklist

Material PVC PP POF
Thickness(mm) 0.02-0.06 0.02-0.04 0.03-0.1
Heating time(s) 5-10 6-12 8-16
Shrink temperature(℃) 110-130 130-170 130-170

shrink wrap packing machine

Industrial Shrink Wrap Packing Machine Features

1. Heat-shrinkable packaging is one of the more advanced packaging methods in the market. It is wrapped around the product or package by shrink film. After heating, the shrink film is wrapped around the product or package to fully display the appearance of the product and improve its stabilization of the product. Aesthetic and value.
2. The heat-shrinkable package can seal against moisture, prevent pollution, and protect the product from external impact, and has a certain cushioning property. It also reduces the possibility of the product being stolen.
3. This set of equipment adopts a constant temperature aluminum alloy sealing knife, which will not break the wire, ensuring any coking, no smoke, and zero pollution.
4. The finished product conveyor belt is automatically output and the conveying time can be adjusted.
5. The whole set of actions is automatically completed by the cylinder, which greatly reduces the work intensity and increases production efficiency.
6. The cutter has an automatic protection function to prevent the miss-cutting of the package and ensure the safety of the operator.
7. The whole QL5545 +BS-D4520 Shrink machine can be unmanned, can be directly connected to the production line, and the packaging is more automated.
